https_ca

TLS

SSL Server Test (Powered by Qualys SSL Labs)

https://gist.github.com/Karewan/4b0270755e7053b471fdca4419467216

Check CA

openssl x509 -in ca.crt -text -noout

https://www.youtube.com/watch?v=JA0vaIb4158&t=876s

https://www.youtube.com/watch?v=AlE5X1NlHgg

https://www.youtube.com/watch?v=j9QmMEWmcfo

Post

https://jsonplaceholder.typicode.com/posts

request

:method: POST
:path: /posts
:authority: jsonplaceholder.typicode.com
:scheme: httpscontent-type: application/x-www-form-urlencodedcontent-length: 42
accept-encoding: gzipuser-agent: okhttp/5.0.0-SNAPSHOT

response

:status: 201
date: Wed, 17 Apr 2024 06:45:30 GMTcontent-type: application/json; charset=utf-8
content-length: 82
location: https://jsonplaceholder.typicode.com/posts/101
report-to: {"group":"heroku-nel","max_age":3600,"endpoints":[{"url":"https://nel.heroku.com/reports?ts=1713336330&sid=e11707d5-02a7-43ef-b45e-2cf4d2036f7d&s=Hua%2F7slOIpUhGTDPNaKu4xbP%2Bjuwplp9ehOh7C014ok%3D"}]}
reporting-endpoints: heroku-nel=https://nel.heroku.com/reports?ts=1713336330&sid=e11707d5-02a7-43ef-b45e-2cf4d2036f7d&s=Hua%2F7slOIpUhGTDPNaKu4xbP%2Bjuwplp9ehOh7C014ok%3D
nel: {"report_to":"heroku-nel","max_age":3600,"success_fraction":0.005,"failure_fraction":0.05,"response_headers":["Via"]}
x-powered-by: Express
x-ratelimit-limit: 1000
x-ratelimit-remaining: 999
x-ratelimit-reset: 1713336348
vary: Origin, X-HTTP-Method-Override, Accept-Encoding
access-control-allow-credentials: true
cache-control: no-cachepragma: no-cacheexpires: -1
access-control-expose-headers: Location
x-content-type-options: nosniffetag: W/"52-HKy3Gu5DcI5r2jj3f8TQwnYvlDs"
via: 1.1 vegurcf-cache-status: DYNAMICserver: cloudflarecf-ray: 875a73ddee780484-HKGalt-svc: h3=":443"; ma=86400

GET

https://api.github.com/repos/square/okhttp/contributors

Request

:method: GET
:path: /repos/square/okhttp/contributors
:authority: api.github.com
:scheme: httpsaccept-encoding: gzipuser-agent: okhttp/5.0.0-SNAPSHOT

Response

:status: 200
server: GitHub.comdate: Wed, 17 Apr 2024 06:58:41 GMTcontent-type: application/json; charset=utf-8
cache-control: public, max-age=60, s-maxage=60
vary: Accept, Accept-Encoding, Accept, X-Requested-With
etag: W/"699b092aa0b0980f1b2f2bde5e810a75c5c1921ee2f53c4d9f28fc8ea5fca327"
last-modified: Wed, 17 Apr 2024 02:18:24 GMTx-github-media-type: github.v3; format=jsonlink: <https://api.github.com/repositories/5152285/contributors?page=2>; rel="next", <https://api.github.com/repositories/5152285/contributors?page=9>; rel="last"
x-github-api-version-selected: 2022-11-28
access-control-expose-headers: ETag, Link, Location, Retry-After, X-GitHub-OTP, X-RateLimit-Limit, X-RateLimit-Remaining, X-RateLimit-Used, X-RateLimit-Resource, X-RateLimit-Reset, X-OAuth-Scopes, X-Accepted-OAuth-Scopes, X-Poll-Interval, X-GitHub-Media-Type, X-GitHub-SSO, X-GitHub-Request-Id, Deprecation, Sunset
access-control-allow-origin: *
strict-transport-security: max-age=31536000; includeSubdomains; preloadx-frame-options: denyx-content-type-options: nosniffx-xss-protection: 0
referrer-policy: origin-when-cross-origin, strict-origin-when-cross-origincontent-security-policy: default-src 'none'
content-encoding: gzipx-ratelimit-limit: 60
x-ratelimit-remaining: 55
x-ratelimit-reset: 1713337679
x-ratelimit-resource: corex-ratelimit-used: 5
accept-ranges: bytesx-github-request-id: 200C:21C6BE:267A047:2720F58:661F7320

Key Points

• Deprecation of TLS 1.0 and 1.1:
  Android 10 disables TLS 1.0 and TLS 1.1 by default due to known vulnerabilities in these older protocols.
• Enhanced Security:
  By requiring TLS 1.2 or newer, Android 10 and later versions improve the security of network communications.
• Developer Implications:
  Apps that rely on legacy servers supporting only TLS 1.0 or TLS 1.1 may encounter connection issues on devices running Android 10 or higher. Developers are encouraged to update their server configurations and client code to support TLS 1.2 or TLS 1.3.
• Industry Alignment:
  This move is in line with broader industry trends, where many platforms and browsers have also phased out support for TLS 1.0 and 1.1.

If you’re maintaining an app or server infrastructure, it’s important to verify that your connections support TLS 1.2 or higher to ensure compatibility with Android 10+ devices.

Self‑Signed CA

Step 1. Create a Self‑Signed CA with SANs

1.1 Create an OpenSSL Configuration File for the CA (ca.cnf)

Create a file named ca.cnf with the following content. This file tells OpenSSL to include SANs in the CA certificate and sets the proper CA extensions.

ini

Copy

[ req ]
default_bits       = 4096
prompt             = no
default_md         = sha256
distinguished_name = dn
x509_extensions    = v3_ca

[ dn ]
C  = US
ST = State
L  = City
O  = MyOrg
OU = MyUnit
CN = MyLocalCA

[ v3_ca ]
# Add Subject Alternative Names to the CA certificate
subjectAltName = @alt_names
# Indicate this certificate is a CA
basicConstraints = critical, CA:TRUE, pathlen:0
keyUsage = critical, digitalSignature, cRLSign, keyCertSign
subjectKeyIdentifier = hash

[ alt_names ]
DNS.1 = myca.realmjon.mynetgear.com
DNS.2 = ca.realmjon.mynetgear.com

1.2 Generate the CA Key and Certificate

Run these commands in your terminal:

bash

Copy

# Generate the CA private key
openssl genrsa -out ca.key 4096

# Generate the self‑signed CA certificate (valid for 10 years)
openssl req -x509 -new -nodes -key ca.key -sha256 -days 3650 \
  -out ca.crt -config ca.cnf

After this step, ca.crt is your CA certificate (including the SANs defined in ca.cnf).

---

Step 2. Create a Server Certificate for “realmjon.mynetgear.com” with SANs

2.1 Create an OpenSSL Configuration File for the Server (server.cnf)

Create a file named server.cnf with the following content:

ini

Copy

[ req ]
default_bits       = 2048
prompt             = no
default_md         = sha256
distinguished_name = dn
req_extensions     = req_ext

[ dn ]
C  = US
ST = State
L  = City
O  = MyOrg
OU = MyUnit
CN = realmjon.mynetgear.com

[ req_ext ]
# Add Subject Alternative Names for the server certificate
subjectAltName = @alt_names

[ alt_names ]
DNS.1 = realmjon.mynetgear.com
DNS.2 = www.realmjon.mynetgear.com
DNS.3 = api.realmjon.mynetgear.com

Adjust or add additional DNS (or IP) entries as needed.

2.2 Generate the Server Key and CSR

Run the following commands:

bash

Copy

# Generate the server private key
openssl genrsa -out server.key 2048

# Create a Certificate Signing Request (CSR) using the config file
openssl req -new -key server.key -out server.csr -config server.cnf

2.3 Sign the Server CSR with Your CA

Sign the CSR with your CA certificate and key to generate the server certificate. This process will embed the SANs into the certificate.

bash

Copy

openssl x509 -req -in server.csr -CA ca.crt -CAkey ca.key -CAcreateserial \
  -out server.crt -days 3650 -sha256 -extfile server.cnf -extensions req_ext

Now, server.crt is your server certificate for realmjon.mynetgear.com with the specified SANs.

---

Step 3. Package the Server Certificate and Key into a PKCS#12 Keystore

Spring Boot can load your certificate and key from a PKCS#12 keystore. Create it with:

bash

Copy

openssl pkcs12 -export -in server.crt -inkey server.key \
  -out server.p12 -name springboot -CAfile ca.crt -caname root

When prompted, enter an export password (which you’ll later use in your Spring Boot configuration).

---

Step 4. Configure Spring Boot to Use the Keystore

Place server.p12 in your Spring Boot project’s src/main/resources directory, and update your application.properties (or YAML) file with:

properties

Copy

server.port=8443
server.ssl.enabled=true
server.ssl.key-store=classpath:server.p12
server.ssl.key-store-password=your_keystore_password
server.ssl.key-store-type=PKCS12
server.ssl.key-alias=springboot

Replace your_keystore_password with the password you set during the PKCS#12 export.

---

Step 5. Verify the Certificates with OpenSSL

5.1 Verify CA Certificate SANs

Run this command to print the details of your CA certificate and check its SANs:

bash

Copy

openssl x509 -in ca.crt -text -noout | grep -A1 "Subject Alternative Name"

You should see something like:

ruby

Copy

        `X509v3 Subject Alternative Name:                 DNS:myca.realmjon.mynetgear.com, DNS:ca.realmjon.mynetgear.com`

5.2 Verify Server Certificate SANs

Similarly, check your server certificate:

openssl x509 -in server.crt -text -noout | grep -A1 "Subject Alternative Name"

Expected output:

        `X509v3 Subject Alternative Name:                 DNS:realmjon.mynetgear.com, DNS:www.realmjon.mynetgear.com, DNS:api.realmjon.mynetgear.com`

Step6. OkHttp Demo Code

Below is an example Java class demonstrating how to load the CA from assets, configure the SSL context for TLSv1.3, and make an asynchronous HTTPS request using OkHttp. Make sure to execute network calls off the main thread (this example uses a separate thread):

import android.content.Context;
import android.util.Log;
import java.io.InputStream;
import java.security.KeyStore;
import java.security.cert.Certificate;
import java.security.cert.CertificateFactory;
import javax.net.ssl.SSLContext;
import javax.net.ssl.TrustManager;
import javax.net.ssl.TrustManagerFactory;
import javax.net.ssl.X509TrustManager;
import okhttp3.Call;
import okhttp3.Callback;
import okhttp3.OkHttpClient;
import okhttp3.Request;
import okhttp3.Response;
import javax.net.ssl.HostnameVerifier;
import javax.net.ssl.SSLSession;
import java.io.IOException;

public class OkHttpSelfSignedDemo {

    public static void makeRequest(final Context context) {
        new Thread(() -> {
            try {
                // Load the CA certificate from the assets folder
                CertificateFactory cf = CertificateFactory.getInstance("X.509");
                InputStream caInput = context.getAssets().open("ca.crt");
                Certificate ca = cf.generateCertificate(caInput);
                caInput.close();

                // Create a KeyStore containing the trusted CA
                KeyStore keyStore = KeyStore.getInstance(KeyStore.getDefaultType());
                keyStore.load(null, null);
                keyStore.setCertificateEntry("ca", ca);

                // Create a TrustManager that trusts the CA in our KeyStore
                TrustManagerFactory tmf = TrustManagerFactory.getInstance(
                        TrustManagerFactory.getDefaultAlgorithm());
                tmf.init(keyStore);
                TrustManager[] trustManagers = tmf.getTrustManagers();
                X509TrustManager trustManager = null;
                for (TrustManager tm : trustManagers) {
                    if (tm instanceof X509TrustManager) {
                        trustManager = (X509TrustManager) tm;
                        break;
                    }
                }
                if (trustManager == null) {
                    throw new IllegalStateException("No X509TrustManager found");
                }

                // Create an SSLContext for TLSv1.3
                SSLContext sslContext = SSLContext.getInstance("TLSv1.3");
                sslContext.init(null, new TrustManager[]{trustManager}, null);

                // Build the OkHttpClient with the custom SSL settings
                OkHttpClient client = new OkHttpClient.Builder()
                        .sslSocketFactory(sslContext.getSocketFactory(), trustManager)
                        .hostnameVerifier(new HostnameVerifier() {
                            @Override
                            public boolean verify(String hostname, SSLSession session) {
                                // Accept the specific IP address (replace with your actual server IP)
                                return hostname.equals("192.168.1.100");
                            }
                        })
                        .build();

                // Build and execute the HTTPS request (adjust URL, port, and path as needed)
                Request request = new Request.Builder()
                        .url("https://192.168.1.100:8443/")
                        .build();

                client.newCall(request).enqueue(new Callback() {
                    @Override
                    public void onFailure(Call call, IOException e) {
                        Log.e("OkHttpDemo", "Request failed", e);
                    }

                    @Override
                    public void onResponse(Call call, Response response) throws IOException {
                        if (!response.isSuccessful()) {
                            throw new IOException("Unexpected code " + response);
                        }
                        String responseBody = response.body().string();
                        Log.d("OkHttpDemo", "Response: " + responseBody);
                    }
                });
            } catch (Exception e) {
                Log.e("OkHttpDemo", "Error setting up HTTPS connection", e);
            }
        }).start();
    }
}

HTTPS

Springboot配置openssl生成的证书 - lovelylily - 博客园

Springboot 证书配置实战Springboot证书配置实战 创建证书 生成CA证书 生成CA证书 将CA证书加到 - 掘金

generate host “realmjon.mynetgear.com” self-sign CA make both server.crt ca.crt have subjectalternativenames , config in the springboot

ChatGPT said:

Reasoned for 17 seconds

Below is a complete guide that shows you how to create a self‑signed CA and use it to sign a server certificate for the host realmjon.mynetgear.com, ensuring that both the CA certificate and the server certificate include Subject Alternative Names (SANs). Finally, you’ll see how to package the server certificate into a PKCS#12 keystore for Spring Boot configuration.

Summary

1. Local CA Creation:

   • Created a self‑signed CA certificate (ca.crt) that includes SANs (via ca.cnf).

2. Server Certificate:

   • Generated a CSR and signed it with the CA to produce server.crt for realmjon.mynetgear.com with SANs (via server.cnf).

3. PKCS#12 Keystore:

   • Combined the server certificate and key (with the CA certificate) into server.p12.

4. Spring Boot Configuration:

   • Configured Spring Boot to use server.p12 for HTTPS.

5. Verification:

   • Used OpenSSL commands to verify that both certificates contain the correct SAN entries.

Following these steps ensures that both your CA and server certificates include the desired Subject Alternative Names and that your Spring Boot application is correctly configured for HTTPS.
